Fully automatic butt welding machine for closed pipes in all positions
Fully automatic butt welding machine for closed pipes in all positions
- Description
- Reviews (0)
- Product Attributes
Description
Model: ET-20W
Duty cycle: 200A 60% /155A 100%
Welding current: 5~200 A
No-load voltage: 65V
Input voltage: AC220V 10% 50Hz/60Hz
Power: 4.5 KVA
Gun cooling: built-in circulating water cooling
Display: 10-inch touch screen
Storable programs: 99
Dividable intervals: 12
Insulation level/protection level: F/IP21
Water tank capacity: 4L
Weight: 33KG (including cooling water 3.7L)
Dimensions (mm): 510 × 353 X 340mm
Control function: DC/pulse current control, gas control, rotational motion, automatic/manual
Protection function: overvoltage, overload, leakage, arc failure and tungsten needle short circuit protection, missing item detection
Duty cycle: 200A 60% /155A 100%
Welding current: 5~200 A
No-load voltage: 65V
Input voltage: AC220V 10% 50Hz/60Hz
Power: 4.5 KVA
Gun cooling: built-in circulating water cooling
Display: 10-inch touch screen
Storable programs: 99
Dividable intervals: 12
Insulation level/protection level: F/IP21
Water tank capacity: 4L
Weight: 33KG (including cooling water 3.7L)
Dimensions (mm): 510 × 353 X 340mm
Control function: DC/pulse current control, gas control, rotational motion, automatic/manual
Protection function: overvoltage, overload, leakage, arc failure and tungsten needle short circuit protection, missing item detection
Be the first to review “Fully automatic butt welding machine for closed pipes in all positions”
Weight: 33000g
Power type: Fully automatic docking machine
Working principle: Closed pipe welding machine
Material: Full-position pipe automatic welding machine
Current type: DC
Model: ET-20W
Power: 22W
